I.42
Part. N. 8000 H1344 (10-2009)
FRONT SUSPENSION
Remove the stop ring using a slotted screwdriver.
Remove the inner tube from the outer tube.
N.B.: to make this operation easier, push the tubes back and forth several times
Remove the seal rings and the metallic rings mounted on the inner tube.
Do not re-use any metallic parts which are disassembled.
Replace with new parts.
Replace any damaged seal rings.
The washer and the stop ring can be re-used, if not damaged.
Check that the inner push rod is not distorted or damaged.
Replace if necessary.
Check the bottom valve unit.
Replace any damaged O-rings.
Replace the entire unit (Do not re-use).
