I.46
Part. N. 8000 H1344 (10-2009)
FRONT SUSPENSION
Assemble the collar bushing, the O-ring, the spring guide and the nut on the
piston rod.
Insert the inner push rod into the piston rod.
Make sure that the inner push rod protrudes at least 18mm (0.71in.) from the
piston rod.
Move the piston rod slowly up and down to evenly distribute the oil in the entire
cartridge.
N.B.: If, during assembly, the oil has not been completely drained from the
