M.44 Part. N. 8000 H1344 (10-2009)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
• Connecting the injector
Connect the injector connector as shown.
• Connecting the central unit
Connect the central unit connector as shown.
• Ignition coil connection
Connect the ignition coil connector as shown
• Positioning of the fuel pump connector
Place the fuel pump connector as shown.
