M.52 Part. N. 8000 H1344 (10-2009)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
• Fastening wiring
Connect the start and speed sensor cable bundle to the hydraulic clutch pipe.
• Fastening wiring
Fasten the front wire harness with two clamps as shown.
• Fastening wiring
Fasten the front wire harness with two clamps as shown.
