N.3Part. N. 8000 H1344 (10-2009)
ENGINE COOLING SYSTEM
Checking the cooling uid level
Cooling uid absorbs the heat from the thermic group (piston, cylinder, head) and
conveys it to the exterior atmosphere through radiator. For a correct operation of
the cooling system it is of utmost importance the periodical check of uid level.
The lack of the heat exchange means (water) between thermic mass and
radiant mass could cause overheating of the cylinder-piston assembly with
consequent seizure and, the worst, damages to the crankshaft assembly.
However if engine overheating is noticed, check that radiator is completely lled
up.
Check of radiator level must be performed with cold engine (see page D.32).
If for any reason you have to operate on a hot engine, take care to slowly dis-
charge pressure.
The radiator cap (1) is provided of two unlocking positions, the rst being for the
previous pressure discharge.
Opening the circuit without taking care of above directions could
cause scalds to the operator and other people around.
TE-SMR: Because the cooling fan (2) can be activated even when
the start switch is in OFF position, always keep at a safe distance
from the fan vanes.
A. Cooling uid level
B. Breather hose
2
