HYDRAULIC CONTROL CLUTCH
Hydraulic clutch system
The hydraulic system consists of a pump with its own tank, placed on handlebar
L.H. side, and a small piston, placed in the L.H. engine crankcase. The clutch
desengagement is effectued by the slave cylinder (5) that, acting on the push
rod, move the pressure disc (6). The drive between the crankshaft (a) and the
main shaft (b) of the gearbox is effected by the gear on the clutch housing (8).
The clutch housing contains both the driving discs (9) and driven discs (10); the
driven discs move the clutch hub (11) fastened on the gearbox main shaft.
1- Clutch master cylinder
2- Clutch control lever
3- Master cylinder/ slave cylinder hose
4- Push rod
5- Clutch slave cylinder
6- Pressure disc
7- Bleeder valve
8- Clutch housing with clutch ring gear
9- Clutch driving disc
10- Clutch driven disc
11- Clutch hub
a- Crankshaft
b- Main shaft
Since the uid employed inside the hydraulic system can damage
the paint, pay the utmost attention during every operation to the
system.
