X.4 Part. N. 8000 H1344 (10-2009)
TORQUE WRENCH SETTINGS
TIGHTENING TORQUES (+/- 5%)
CHASSIS
Application
Frame to tie rod fastening nut........................................................................................................M12x1,25 80 Nm 8,2 Kgm 59 ft/lb
Rocker arm to tie rod lubricator .....................................................................................................M6x1 2,95 Nm 0,3 Kgm 2,2 ft/lb
Rear shock absorber to frame fastening pivot ...............................................................................M10x1,25 52,4 Nm 5,35 Kgm 38,6 ft/lb
Rocker arm to frame fastening pivot..............................................................................................M10x1,25 52,4 Nm 5,35 Kgm 38,6 ft/lb
Chain guide to rear swing arm fastening screw (TE-SMR) ..........................................................M8x1,25 25 Nm 2,5 Kgm 18.4 ft/lb
Chain guide to rear swing arm front fastening screw (TC) ............................................................M8x1,25 (+LOCTITE 243) 10,4 Nm 1,05 Kgm 7.7 ft/lb
Chain guide to rear swing arm rear fastening screw (TC) .............................................................M6x1 (+LOCTITE 243) 10,4 Nm 1,05 Kgm 7.7 ft/lb
Bracket to chain guide fastening screw (TE-SMR) ........................................................................M6x1 (+LOCTITE 243) 2 Nm 0,2 Kgm 1.5 ft/lb
Chain slider and rear brake hose clamp lower fastening screw .................................................... M5x0,8 4,4 Nm 0,45 Kgm 3.2 ft/lb
Chain slider and rear brake hose clamp reear fastening screw (TC-TXC) ...................................M5x0,8 4,4 Nm 0,45 Kgm 3.2 ft/lb
Chain guard fastening screw (TE-SMR) ........................................................................................M5x0,8 4,4 Nm 0,45 Kgm 3.2 ft/lb
Chain adjuster fastening nut ..........................................................................................................M8x1,25 4,4 Nm 0,45 Kgm 3.2 ft/lb
Spoiler to fuel tank fastening screw ...............................................................................................M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Front number holder upper fastening screw (TC-TXC) .................................................................M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Front number holder lower fastening screw (TC-TXC) ..................................................................M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Rear shock absorber guard fastening screw ................................................................................M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Rear fender front fastening screw .................................................................................................M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Rear fender rear fastening screw ..................................................................................................M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Front fender fastening screw .........................................................................................................M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Radiator guard fastening screw .....................................................................................................M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Side panel fastening screw ...........................................................................................................M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
License plate fastening screw .......................................................................................................M6x1 6 Nm 0,6 Kgm 4.4 ft/l
Rear reector fastening nut ...........................................................................................................M4x0,7 1,9 Nm 0,2 Kgm 1.4 ft/lb
Brake hose ring to front fairing fastening screw ............................................................................ø 3,5 1,9 Nm 0,2 Kgm 1.4 ft/lb
Turn signals fastening screw .........................................................................................................M6x1 6 Nm 0,6 Kgm 4.4 ft/lb
Front headlamp fastening screw ...................................................................................................ø 3,9 1,45 Nm 0,15 Kgm 1 ft/lb
Electric start remote control switch cables fastening screw ..........................................................M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Fuel tank front rubber pad fastening screw ...................................................................................M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Fuel cock fastening screw .............................................................................................................ø5,5 2,45 Nm 0,25 Kgm 1.8 ft/lb
Fuel tank rear fastening screw ......................................................................................................M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
Air lter box front fastening screw .................................................................................................M6x1 10,4 Nm 1,05 Kgm 7.7 ft/lb
