Y.8 Part. N. 8000 H1344 (10-2009)
FRAME AND WHEELS
Fit the L.H. spacer on the wheel hub.
TE-TC-TXC: Fit the wheel between the front fork legs so that the brake disc is
tted into the caliper.
SMR: Fit the wheel between the front fork legs.
Fit the wheel axle (2) from the R.H. side, after greasing it and push it to the stop
on the L.H. leg; during this operation, the wheel should be turned.
TE-TC-TXC
TE-TC-TXC
2
1
1
2
SMR
