E.5Part. N. 8000 H1344 (10-2009)
GENERAL OPERATIONS
TC-TXC
2) Remove the breather hose (1) from the steering axle. Turn the ring nut of the
fuel tap (2) anticlockwise to stop fuel owing and loosen the clamp (3) on the
carburettor fuel pipe; remove this pipe from the carburettor and pour the remain-
ing fuel into a container.
Remove the fuel tank fastening screw (4) and, pushing upward slightly in the
front zone of the conveyors, release them from the spoilers on the radiators.
Remove the fuel tank assy. with conveyors.
1
2
3
4
