IAI PCON-CB series User Manual

4. Operation
4.2 Operation in Positioner Mode
4-38 ME0342-4B
Caution
● Set the period taken from entering position No. to turning CSTR ON to 6ms or larger. In
spite of 6ms timer process in the PLC, commands may be input to the controller
concurrently to cause positioning to another position. Take the scanning time in the PLC
into account to set a period as 2 to 4 times as the scanning time. Set the value similarly
if the PLC reads the complete position.
● At the completion of positioning, positioning complete signal PEND is not turned ON if
start signal SCTR remains ON. If this occurs, turn CSTR OFF then PEND is turned ON
immediately.
Therefore, create the sequence program so that turning PEND ON makes CSTR turned
OFF and the PLC waits for the state in which PEND is turned ON.
● At the positioning to the position same as that specified in the stop (complete) position
number, PEND is turned OFF once but moving signal MOVE is not turned ON.
Therefore, use PEND to turn CSTR OFF.
● MOVE turns on at the same time as PEND turns OFF, and turns OFF when a
movement command is finished or PEND is turned ON. Therefore, when the positioning
band setting is wide, the signal may turn OFF even in the actuator operation, and may
turn off prior to PEND if the positioning band setting is narrow.
■ Binary data : ON : OFF
Command position
No.
PC256 PC128 PC64 PC32 PC16 PC8 PC4 PC2 PC1
Completed position
No.
PM256 PM128 PM64 PM32 PM16 PM8 PM4 PM2 PM1
0
        
1
        
2
        
3
        
4
        
5
        
6
        
7
        
8
    
○
  
9
    
○
  
… … … … … … … … … …
509
        
510
        
511
        
