IAI PCON-CB series User Manual

6. Parameter
6.1 Parameter
6-5 ME0342-4B
Parameter List (4/5)
No.
Category
Name Unit Input Range Default factory setting
Compatible
controller type
(Note 3)
Relevant
sections
Pulse Train
Positioner
Pulse Train
Pulse Press
90 C Fieldbus I/O format
(Note4)
- 0 to 3 Separate volume ○ - ○ 6.1.2 [67]
91 C
Current limit value at
stopping due to miss-
pressing
-
0: Current limit value
during movement
1: Current limit value
during pressing
0 ○ - ○ 6.1.2 [68]
92 C Select Use of Loadcell -
0: Does not use
1: Use
In accordance with actuator
(Note2)
- - ○ 6.1.2 [69]
93 C Select Pressing Control -
0: Current control
1: Force sencer
In accordance with actuator
(Note2)
- - ○ 6.1.2 [70]
94 C
Force Sensor Used
Pressing Gain
- 100 to 999,999 In accordance with actuator
(Note2)
- -
○
6.1.2 [71]
95 C
Force Judgment Margin
Positive Side
%
From 1 to
Max. Pressing Force
In accordance with actuator
(Note2)
- -
○
6.1.2 [72]
96 C
Force Judgment Margin
Negative Side
%
From 1 to
Max. Pressing Force
In accordance with actuator
(Note2)
- - ○ 6.1.2 [72]
110 B Stop method at servo OFF -
0: Rapid stop
1: Deceleration to stop
0 ○ - ○ 6.1.2 [73]
111 B Calendar function -
0: Does not use the
calendar timer
1: Use the calendar timer
1 ○ ○ ○ 6.1.2 [74]
112 B Monitoring mode -
0: Does not use
1: Monitor function 1
2: Monitor function 2
3: Monitor function 3
1 ○ ○ ○ 6.1.2 [75]
113 B Monitoring period ms 1 to 60,000 1 ○ ○ ○ 6.1.2 [76]
117 B
Automatic Loadcell
Calibration at Startup
-
0: Not to Perform
1: To Perform
1 - - ○ 6.1.2 [77]
118 B
Pressing Operation when
Loadcell Calibration
Incomplete
-
0: To Prohibit
1: To Accept
0 - - ○ 6.1.2 [78]
119 B Loadcell Calibration Time ms 1 to 9,999 10 - - ○ 6.1.2 [79]
140 B IP address
(Note4)
- 0.0.0.0 to 255.255.255.255 Separate volume ○ - ○
6.1.2 [80]
Separate volume
141 B Subnet mask
(Note4)
- 0.0.0.0 to 255.255.255.255 Separate volume ○ - ○
6.1.2 [81]
Separate volume
142 B Default gateway
(Note4)
- 0.0.0.0 to 255.255.255.255 Separate volume ○ - ○
6.1.2 [82]
Separate volume
143 B Overload level ratio % 50 to 100 100 ○ - ○ 6.1.2 [83]
144 B
Gain scheduling upper limit
multiplying ratio
% 0 to 1,023 0 ○ - ○ 6.1.2 [84]
145 C
GS velocity loop
proportional gain
- 1 to 99,999,999 In accordance with actuator
(Note2)
○ - ○ 6.1.2 [85]
146 C
GS velocity loop integral
gain
- 1 to 99,999,999 In accordance with actuator
(Note2)
○ - ○ 6.1.2 [86]
147 B
Total movement count
threshold
Times 0 to 999,999,999 0 (Disabling) ○ - ○ 6.1.2 [87]
148 B
Total operated distance
threshold
m 0 to 999,999,999 0 (Disabling) ○ ○ ○ 6.1.2 [88]
149 B Zone output changeover -
0: Not to change
1: To change
0 ○ - ○ 6.1.2 [89]
Note 2 The setting values vary in accordance with the specification of the actuator. At shipment, the parameters are set in
accordance with the specification.
Note 3 Positioner: for Positioner Mode, Pulse Train: for Pulse Train Mode, Pulse Press: for Pulse Press Train Control (PCON-CBP)
Note 4 These parameters are exclusively used for the field network type.
