6. Parameter
6.1 Parameter
6-33 ME0342-4B
[51] Command pulse input mode (Parameter No.63) …Pulse train only
No. Name Unit Input range Default initial value setting
63 Command pulse input mode - 0 to 2 1
This parameter is exclusively used for the pulse-train control mode.
Refer to [4.3.4 Settings of Basic Parameters Required for Operation.]
[52] Command pulse input mode polarity (Parameter No.64) …Pulse train only
No. Name Unit Input range Default initial value setting
64
Command pulse input mode
polarity
-
0: Positive Logic
1: Negative Logic
0
This parameter is exclusively used for the pulse-train control mode.
Refer to [4.3.4 Settings of Basic Parameters Required for Operation.]
[53] Electronic gear numerator (Parameter No.65) …Pulse train only
No. Name Unit Input range Default initial value setting
65 Electronic gear numerator - 1 to 4096 200
This parameter is exclusively used for the pulse-train control mode.
Refer to [4.3.4 Settings of Basic Parameters Required for Operation.]
[54] Electronic gear denominator (Parameter No.66) …Pulse train only
No. Name Unit Input range Default initial value setting
66 Electronic gear denominator - 1 to 4096 15
This parameter is exclusively used for the pulse-train control mode.
Refer to [4.3.4 Settings of Basic Parameters Required for Operation.]
[55] Select enable/disable compulsory stop input (Parameter No.67) …Pulse train only
No. Name Unit Input range Default initial value setting
67
Select enable/disable
compulsory stop input
- 0 : Enabled 1 : Disabled 0
This parameter is exclusively used for the pulse-train control mode.
Refer to [4.3.5 Parameter Settings Required for Advanced Operations.]
