6. Parameter
6.1 Parameter
6-39 ME0342-4B
[69] Select to Use Loadcell (Prameter No. 92) …Pulse press only
No. Name Unit Input range Default initial value setting
92 Select to use loadcell -
0: Not in use,
1: Used
0
Setting to use / not to use the loadcell (option) should be established.
Set value Content
0 Loadcell Not to be Used (for standard actuator)
1
Loadcell to be Used (for actuator (pulse pressing) equipped with loadcell)
Refer to [4.2.8 Preparation for Operation in Force Sensor Pressing (Loadcell Calibration)]
[70] Select Pressing Control (Prameter No. 93) …Pulse press only
No. Name Unit Input range Default initial value setting
93 Select pressing control -
0: Current control
1: Force sencer
In accordance with actuator
The pressing system should be selected.
Set value Content
0 Pressing with Current Limit (for standard actuator)
1 Force Sensor Used Pressing (for actuator equipped with loadcell)
Refer to [4.2.8 Preparation for Operation in Force Sensor Pressing (Loadcell Calibration)]
Select to use loadcell
(Parameter No. 92)
(This Parameter)
(This Parameter)
Force Sensor Pressing
(Conventional System)
Parameter Error Alarm
(Conventional System)
0: Not in use
1: Used
1: Force Sensor
Pressing
0: Pressing with
Current Limit
1: Force Sensor
Pressing
0: Force Sensor
Pressing
