1. Controller Overview
1.3 Name for Each Parts and Their Functions
1-5 ME0342-4B
Caution
● In this manual, each type of CB/CGB is stated as CB, each type of CFB/CGFB as
CFB, and each type of CBP/CGBP as CBP.
1) Absolute Battery Connector: Refer to [3.1.3 (3)]
It is the connector to plug in the enclosed battery if applicable for Simple Absolute Type (option).
* This should not used in CFB and CBP types.
2) Absolute Battery: Refer to [2.6.2]
It is enclosed if applicable for Simple Absolute Type (option).
Use unit by affixing it on the side of PCON body with fabric hook-and-loop fastener or store it
Absolute Battery Unit (option).
* This should not used in CFB and CBP types.
3) Absolute Battery Status Indicator LED
It is equipped if applicable for Simple Absolute Type (option).
It displays the status such as battery charge condition and error generation.
: Illuminating × : OFF
LED Operation status
1 (GN/RD) 0 (GN/OR/RD) Description
× × × Control Power OFF
(GN) (GN)
(Either color)
Absolute Reset Complete
(GN) (RD)
(Either color)
Absolute Reset Incomplete
(RD) (RD)
(Either color)
Error occurred.
(Either color)
(Either color)
(GN) Battery Fully Charged
(Either color)
(Either color)
(OR) Battery Charging Operation
(Either color)
(Either color)
(RD) Battery Disconnected
* This should not used in CFB and CBP types.
