IAI PCON-CB series User Manual

Revision history
Revision history
Post-4 ME0342-4B
Revision date Revised content
2021.05
2021.09
Fourth Edition
Full-Scale Revision
Overall: PCON-CBP/CGBP added in accordance with release of RCP6 pulse
pressing
Descriptions deleted related to actuators applicable for data
management features
4B Edition
1.4 Moved to 2.2
1.5 Pulled up to 1.4, change made to structure
Change made from TB-01 to TB-02 in figure
2.1.3 Correction made to type name explanation
2.2 Operation Modes and Features moved to 1.4, Sections after this
pulled down
2.6.2 Correction made to weight of absolute battery
3.1.2 (2) Correction made to reference description
3.1.3 (1) Correction made to figure of example circuit, description added in
caution
3.1.3 (2) Change made to section name
3.2.2 (1) Correction made to reference description
3.2.3 (1) Correction made to figure of example circuit, description added in
caution
3.3.6 Applicable models for each network type added
4.1.2 Change made from TB-01 to TB-02 in figure, example added for
registration in IA-OS
4.2.5 (1) Figure for zone signal deleted, axis in image changed to new model
4.2.8 (2) Correction made to explanation related to loadcell calibration
6.1.1 Correction made to reference description for 65 and 66
6.1.2 [56] Change made to description regarding position feed forward gain
7.1 Description deleted regarding SCON extension unit
8.2.1 Correction made to reference description
8.3.3 (3) 0A1 (e.g. 4) 0C8 deleted, Correction made to description regarding
0CC Countermeasure (3)
8.3.3 (3) 04C/0CA Description deleted regarding R-unit
0E4 "Driver unit" corrected to "controller"
9.4 Change made partially to actuator specifications
Others Correction made, terms unified

IAI PCON-CB series Specifications

General

Brand	IAI
Model	PCON-CB series
Category	Controller
Language	English
