U
SER
’
S
M
ANUAL
P
REFACE
-1
S
AFETY
P
RECAUTIONS
• Read this user’s manual to make sure of correct operation before starting installation, wiring, operation, maintenance, and
inspection of the
MICRO
3
.
• All
MICRO
3
’s are manufactured under IDEC’s rigorous quality control system, but users must add a backup or failsafe pro-
vision to the control system using the
MICRO
3
in applications where heavy damage or personal injury may be caused in
case the
MICRO
3
should fail.
• In this user’s manual, safety precautions are categorized in order of importance to Warning and Caution:
• Turn power off to the
MICRO
3
before starting installation, removal, wiring, maintenance, and inspection on the
MICRO
3
.
Failure to turn power off may cause electrical shocks or fire hazard.
• Special expertise is required to install, wire, program, and operate the
MICRO
3
. People without such expertise must not use
the
MICRO
3
.
• Emergency and interlocking circuits must be configured outside the
MICRO
3
. If such a circuit is configured inside the
MICRO
3
, failure of the
MICRO
3
may cause disorder of the control system, damage, or accidents.
• Install the
MICRO
3
according to instructions described in this user’s manual. Improper installation will result in falling, fail-
ure, or malfunction of the
MICRO
3
.
•
MICRO
3
is designed for installation in equipment. Do not install the
MICRO
3
outside of equipment.
• Install the
MICRO
3
in environments described in this user’s manual. If the
MICRO
3
is used in places where the
MICRO
3
is
subjected to high-temperature, high-humidity, condensation, corrosive gases, excessive vibrations, and excessive shocks,
then electrical shocks, fire hazard, or malfunction will result.
• The pollution degree of the
MICRO
3
is “Pollution degree 2.” Use the
MICRO
3
in environments of pollution degree 2 (accord-
ing to IEC664-1).
• All DC power type
MICRO
3
units are “PS2” type (according to EN61131).
• Prevent the
MICRO
3
from falling while moving or transporting the
MICRO
3
, otherwise damage or malfunction of the
MICRO
3
will result.
• Prevent metal fragments and pieces of wire from dropping inside the
MICRO
3
housing. Put a cover on the
MICRO
3
during
installation and wiring. Ingress of such fragments and chips may cause fire hazard, damage, or malfunction.
• Use a power supply of the rated value. Use of a wrong power supply may cause fire hazard.
• Use wires of a proper size to meet voltage and current requirements. Tighten M3 terminal screws to a proper tightening
torque of 0.3 to 0.5 N-m.
• Use an IEC127-approved fuse on the power line outside the
MICRO
3
. This is required when exporting equipment containing
MICRO
3
to Europe.
• Use an IEC127-approved fuse on the output circuit. This is required when exporting equipment containing
MICRO
3
to
Europe.
• Use an EU-approved circuit breaker. This is required when exporting equipment containing
MICRO
3
to Europe.
• Make sure of safety before starting and stopping the
MICRO
3
or when operating the
MICRO
3
to force outputs on or off.
Incorrect operation on the
MICRO
3
may cause machine damage or accidents.
• If relays or transistors in the
MICRO
3
output circuit fail, outputs may remain on or off. For output signals which may cause
heavy accidents, provide a monitor circuit outside of the
MICRO
3
.
• Do not connect to the ground directly from the
MICRO
3
. Connect a protective ground to the equipment containing
MICRO
3
using an M4 or larger screw. This is required when exporting equipment containing
MICRO
3
to Europe.
• Do not disassemble, repair, or modify the
MICRO
3
.
• Dispose of the battery in the
MICRO
3
when the battery is dead in accordance with pertaining regulations. When storing or
disposing of the battery, use a proper container prepared for this purpose. This is required when exporting equipment con-
taining
MICRO
3
to Europe.
• When disposing of the
MICRO
3
, do so as an industrial waste.
• Dispose of the battery in the memory card when the battery is dead in accordance with pertaining regulations.
Warning
Caution
Warning notices are used to emphasize that improper operation may cause
severe personal injury or death.
Caution notices are used where inattention might cause personal injury or
damage to equipment.
Warning
Caution
