IDEC MICRO3 User Manual

3: PROGRAM LOADER
USER’S MANUAL 3-7
Inserting Program Instructions
A program instruction can be inserted at any address. When a program instruction is inserted, subsequent program instruc-
tions are shifted down.
Move the cursor to the address where you want to insert a program instruction.
Press the INS key.
Enter the program instruction to insert, and press the key.
To insert more instructions, continue to enter the instructions.
To return to the normal editor mode, press the CLR key.
Example: Insert an NO contact of input I2 at the position
*
in the diagram below
This insertion is done by inserting an AND instruction between addresses 12 and 13.
Move the cursor to address 13 by pressing keys:
Press the insert key:
Enter the AND instruction and operand I2:
The cursor moves to the next line.
To return the normal editor mode, press the clear key:
Prgm Adrs Instruction Data
11
12
13
LOD
OR
OUT
I0
I1
Q0
I0
I1
Q0
*
ADRS
3
BPP
1
BPS
12 OR I 1
13 OUT Q 0
14 END
15 END
INS
12 OR I 1
INST
13 OUT Q 0
14 END
AND
D
SET
I
2
BRD
12 OR I 1
13 AND I 2
INST
14 OUT Q 0
CLR
12 OR I 1
13 AND I 2
14 OUT Q 0
15 END
