Hardware Installations and Upgrades
Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide (Preliminary) 141
Comments: This specifies the IPv6 Prefix Length for the Intel
®
RMM4 DMN LAN.
There is a separate IPv6 Prefix Length field for the Baseboard LAN configuration.
This option is only visible when the IPv6 option is set to Enabled.
When IPv6 addressing is used, the initial value for this field is acquired from the BMC. The
setting of IPv6 Source determines whether this field is display-only (when Dynamic or Auto) or
can be edited (when Static).
Back to [BMC LAN Configuration]
19. BMC DHCP Host Name
Option Values: [Entry Field, 2-63 characters]
Help Text:
View/Edit BMC DHCP host name. Press <Enter> to edit. Host name should start with an
alphabetic, remaining can be alphanumeric characters. Host name length may be from 2
to 63 characters.
Comments: This field is active and may be edited whenever at least one of the IP
Source or IPv6 Source options is set to Dynamic. This is the name of the DHCP Host from
which dynamically assigned IPv4 or IPv6 addressing parameters are acquired.
The initial value for this field is supplied from the BMC, if there is a DHCP Host available. The
user can edit the existing Ho or enter a different DHCP Host Name.
If none of the IP/IPv6 Source fields is set to Dynamic, then this BMC DHCP Host Name field
will be grayed out and inactive.
Back to [BMC LAN Configuration]
20. User ID
Option Values: anonymous
root
User3
User4
User5
Help Text:
Select the User ID to configure: User1 (anonymous), User2 (root), and User3/4/5 are
supported.
Comments: These 5 User IDs are fixed choices and cannot be changed. The BMC
supports 15 User IDs natively, but only the first 5 are supported through this interface.
Back to [BMC LAN Configuration]
