INVT SV-DA200 Series User Manual

SV-DA200 series AC servo drive Appendix
-275-
Function
code
Name
Unit
Range
Default
Available
Mode
P4.36
1
Undervoltage protection of main
power supply
-
0–1
1
PST
P4.37
Undervoltage detection time of
main power supply
ms
70–2000
70
PST
P4.38
Motor overload rate
%
0.0–500.0
115.0
PST
P4.39
Speed deviation setting
r/min
0–20000
0
PS
P4.40
Forward speed limit
r/min
0–20000
20000
PST
P4.41
Reverse speed limit
r/min
-20000–0
-20000
PST
P4.42
Internal speed of high resolution
r/min
-20000.0–20000.0
0.0
S
P4.45
Temperature protection threshold
of medium-power motor

0–200
0
PST
P4.50
1
Offset of encoder Z phase
pulse
0–(2
20
-1)
0
PST
P4.51
Switching time 1 of torque limit
ms/100%
0–4000
0
PS
P4.52
Switching time 2 of torque limit
ms/100%
0–4000
0
PS
P4.53
Current loop response adjustment
%
10.0–200.0
100.0
PST
P4.54
1
Initialization time after power on
ms
0–200000
0
PST
P4.58
1
Z pulse width of
frequency-division output
pulse
1–255
2
PST
P4.59
Z pulse offset of
frequency-division output
pulse
0–(2
31
-1)
0
PST
P4.60
1
Frequency division molecular of
external linear encoder
-
1–(2
31
-1)
10000
P
P4.61
1
Frequency division denominator
of external linear encoder
-
1–(2
31
-1)
10000
P
P4.62
1
Direction reverse of external
linear encoder
-
0–1
0
P
P4.64
1
Large mixed deviation setting
reference unit
0–2
27
160000
P
P4.65
1
Mixed deviation clearing
r
0–100
0
P
P4.67
1
External linear encoder pulse
output mode of AB phase
-
0–1
0
P
P4.68
1
External linear encoder (2
nd
encoder) resolution
pulse
1–(2
31
-1)
10000
P
P4.69
1
Frequency division output source
-
0–4
0
PST
P4.70
1
External linear encoder (2
nd
encoder) Z signal type
-
0–3
0
PST
P4.78
1
MotionNet node number
-
0–63
0
PST
P4.79
1
MotionNet baud rate
-
0–3
2
PST
P4.80
Configuration of PZD setting
parameter 1
-
1000–3999
1998
PST
