Before you begin installing an uplink module in an EX3200 switch:
•
Ensure that you have taken the necessary precautions to prevent ESD damage (see
“Prevention of Electrostatic Discharge Damage” on page 269).
Ensure that you have the following parts and tools available:
•
Electrostatic discharge (ESD) grounding strap (If a grounding strap is not available,
follow the alternative grounding method described in Step 1 of the following procedure.)
•
Cross-head screwdriver (provided in the uplink module kit)
To install an uplink module in the switch (see Figure 52 on page 197):
1. Attach the electrostatic discharge (ESD) grounding strap to your bare wrist, and
connect the strap to the ESD point on the chassis.
If a grounding strap is not available, hold the uplink module in its antistatic bag in one
hand and touch the exposed, bare metal of the switch with the other hand to ground
yourself and the component.
2. Loosen the screws that secure the flip-up door covering the empty uplink module slot
on the front panel of the switch by using the cross-head screwdriver, flip the door
upward, and remove the blanking panel covering the empty uplink module slot.
NOTE: If you are removing an uplink module and installing another uplink
module, wait for at least 10 seconds after removing the uplink module
before installing the new or the same uplink module. If you do not wait for
at least 10 seconds, the interfaces on the uplink module might not come
up.
3. Taking care not to touch module components, pins, leads, or solder connections,
remove the uplink module from its bag.
CAUTION: Before you slide the uplink module into the slot on the switch
chassis,ensure the uplinkmodule is aligned correctly. Misalignmentmight
cause the pins to bend, making the uplink module unusable.
4. Using both hands, place the module in the empty slot and slide it in gently until it is
fully seated.
5. Flip the door down and tighten the screws by using the cross-head screwdriver.
NOTE: If the switch does not detect the uplink module, see “Troubleshooting
Uplink ModuleInstallation or Replacement on EX3200 Switches” on page232.
Copyright © 2016, Juniper Networks, Inc.196
EX3200 Switch Hardware Guide

Juniper EX3200 Specifications

General

Model	EX3200
Rack Units	1U
Layer Support	Layer 2 and Layer 3
Junos OS	Yes
Maximum VLANs	4093
DRAM	512 MB
Flash Memory	256 MB
Ports	24 or 48
Uplink Ports	4 SFP
Power Supply	AC or DC
MAC Address Table Size	16, 000 entries
Dimensions (W x D x H)	17.4 x 14.4 x 1.7 inches
Weight	12.3 lb (5.6 kg)
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 85% (non-condensing)
