Juniper EX3200 Hardware Guide

Table 13: AC Power Supply LEDs (continued)
State and DescriptionLED
•
Off—Power supply is not sending out power correctly.
•
On—Power supply is sending out power correctly.
DC OK
NOTE: If the AC OK LED and the DC OK LED are unlit, either the AC power
cord is not installed properly or the power supply fuse has failed. If the AC
OK LED is lit and the DC OK LED is unlit, the AC power supply is not installed
properly or the power supply has an internal failure.
Related
Documentation
Power Supply in EX3200 Switches on page 29•
• Connecting AC Power to an EX3200 Switch on page 161
DC Power Supply LEDs in EX3200 Switches
. Table 14 on page 33 describes the LEDs on the DC power supplies.
Table 14: DC Power Supply LEDs
DescriptionColorLED Label
Inputs A and B are normal, but there is no output.RedLED A
RedLED B
Inputs A and B are normal; output is normal.GreenLED A
GreenLED B
Input A has failed because the power supply fuse has failed, input
voltage is low, or there is a loose connection; output is normal.
Flash RedLED A
GreenLED B
Input B has failed because the power supply fuse has failed, input
voltage is low, or there is a loose connection; output is normal.
GreenLED A
Flash RedLED B
Both inputs have failed because the power supply fuse has failed,
input voltage is low, or thereis a looseconnection; output is normal.
Flash RedLED A
Flash RedLED B
There is no input; there is no output.OffLED A
OffLED B
33Copyright © 2016, Juniper Networks, Inc.
Chapter 4: Power Supplies

Juniper EX3200 Specifications

General

Model	EX3200
Rack Units	1U
Layer Support	Layer 2 and Layer 3
Junos OS	Yes
Maximum VLANs	4093
DRAM	512 MB
Flash Memory	256 MB
Ports	24 or 48
Uplink Ports	4 SFP
Power Supply	AC or DC
MAC Address Table Size	16, 000 entries
Dimensions (W x D x H)	17.4 x 14.4 x 1.7 inches
Weight	12.3 lb (5.6 kg)
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 85% (non-condensing)
