Ensure that the wall onto which the switch is installed is stable and securely supported.
If you are mounting the switch in sheetrock (wall board with a gypsum plaster core) or
in wall board not backed by wall studs, use hollow wall anchors capable of supporting
the combined weight of two fully loaded chassis. Insert the screws into wall studs
wherever possible to provide added support for the chassis.
Use the wall-mount kit from Juniper Networks to mount the switch on a wall. The
wall-mount kit is not part of the standard package and must be ordered separately.
Related
Documentation
Clearance Requirements for Airflow and Hardware Maintenance for EX3200 Switches
on page 66
•
• Wall-Mounting Warning for EX3200 Switches on page 252
• Mounting an EX3200 Switch on a Desk or Other Level Surface on page 143
• Mounting an EX3200 Switch on a Wall on page 150
Clearance Requirements for Airflow and Hardware Maintenance for EX3200 Switches
When planning the site for installing an EX3200 switch, you must allow sufficient
clearance around the installed switch (see Figure 19 on page 66).
For the cooling system to function properly, the airflow around the chassis must be
unrestricted. Figure 20 on page 67 shows the airflow through the EX3200 switch chassis
.
Figure 19: Clearance Requirements for Airflow and Hardware Maintenance
for EX3200 Switches
Copyright © 2016, Juniper Networks, Inc.66
EX3200 Switch Hardware Guide
