Table 4: CLI Equivalents of Terms Used in Documentation for EX3200 Switches (continued)
AdditionalInformation
Item in
DocumentationValue (CLI)Description (CLI)Hardware Item (CLI)
Understanding Interface
Naming Conventions on
EX Series Switches
The switch does not
have actual FPCs. In
this case, FPC refers to
the switch itself.
Value of n is always 0.Abbreviated name of
the Flexible PIC
Concentrator (FPC)
One of the following:
•
EX3200-24T
•
EX3200-24P
•
EX3200-48T
•
EX3200-48P
FPC (n)
Understanding Interface
Naming Conventions on
EX Series Switches
The switch does not
have actual PIC
devices; see entries for
PIC 0 through PIC1 for
the equivalent item on
the switch.
n is a value in the range
of 0–1.
Abbreviated name of
the Physical Interface
Card (PIC)
PIC (n)
“Front Panel of an
EX3200 Switch” on
page 9
Built-in network ports
on the front panel of
the switch
PIC 0One of the following:
•
24x 10/100/1000
Base-T
•
48x 10/100/1000
Base-T
“Uplink Modules in
EX3200 Switches” on
page 15
Uplink module
installed on the front
panel of the switch
PIC 1One of the following:
•
2x 10GE SFP+
•
4x GE SFP
•
2x 10 GE XFP
“Pluggable Transceivers
Supported on EX3200
Switches” on page 75
Optical transceiversn is a value equivalent
to the number of the
port in which the
transceiver is installed.
Abbreviated name of
the transceiver
Xcvr (n)
“Power Supply in
EX3200 Switches” on
page 29
AC or DC power supplyValue of n is always 0.
The value corresponds
to the power supply
slot number.
One of the following:
•
PS 320W AC
•
PS 600W AC
•
PS 930W AC
•
PS 190W DC
Power supply (n)
“Cooling System and
Airflow in an EX3200
Switch” on page 27
Fan tray–Fan trayFan tray
Related
Documentation
• EX Series Switches Hardware and CLI Terminology Mapping
• EX3200 Switches Hardware Overview on page 3
Copyright © 2016, Juniper Networks, Inc.6
EX3200 Switch Hardware Guide
