Table 18: Health Status (continued)
DescriptionField
Indicates the memory used in the external Routing Engine.In an EX8200 Virtual Chassis, the memory
utilization value of the XRE200 External Routing Engine in the master role is displayed. Click the
XRE200 External Routing Engine image in the backup role to view the memory used in the backup
external Routing Engine.
Memory util.
Indicates the average CPU usage over 15 minutes.CPU load
Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash
XRE200 External Routing Engines
Indicates the memory used in the external Routing Engine.In an EX8200 Virtual Chassis, the memory
utilization value of the XRE200 External Routing Engine in the master role is displayed. Click the
backup XRE200 External Routing Engine imageto view the memory usedin backup external Routing
Engine.
Memory util.
Indicates the average CPU usage over 15 minutes.CPU load
Indicates the usage and capacity of internal flash memory and any external USB flash drive.Flash
Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent.Fan status
Capacity Utilization Panel
Table 19: Capacity Utilization
DescriptionField
Indicates the number of active ports in the switch. Configured
Virtual Chassis ports (VCPs) are considered as active ports.
Number of active ports
Indicates the number of ports in the switch.
NOTE: In EX3300 Virtual Chassis, the total number of ports
of all of the switches is displayed.
Total number of ports
Indicates the number of MAC table entries.Used-up MAC-Table entries
Indicates the maximum number of MACtable entries permitted.Supported MAC-Table entries
Indicates the number of VLANs configured.
NOTE: Only tagged VLANs are counted.
Number of VLANs configured
Indicates the maximum number of VLANs supported.Number of VLANs supported
Alarms Panel
The Alarms panel displays information about the last five alarms raised in the system.
For example, if there are 5 major alarms, then details of all 5 major alarms are displayed.
41Copyright © 2016, Juniper Networks, Inc.
Chapter 5: Viewing System Information

Juniper EX3200 Specifications

General

Model	EX3200
Rack Units	1U
Layer Support	Layer 2 and Layer 3
Junos OS	Yes
Maximum VLANs	4093
DRAM	512 MB
Flash Memory	256 MB
Ports	24 or 48
Uplink Ports	4 SFP
Power Supply	AC or DC
MAC Address Table Size	16, 000 entries
Dimensions (W x D x H)	17.4 x 14.4 x 1.7 inches
Weight	12.3 lb (5.6 kg)
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 85% (non-condensing)
