Related
Documentation
Connecting AC Power to an EX3200 Switch on page 161•
• Connecting DC Power to an EX3200 Switch on page 163
• Connecting and Configuring an EX Series Switch (CLI Procedure) on page 175
• Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 178
• Clearance Requirements for Airflow and Hardware Maintenance for EX3200 Switches
on page 66
Mounting an EX3200 Switch on Two Posts in a Rack or Cabinet
You can mount an EX3200 switch on two posts of a 19-in. rack (either a two-post or a
four-post rack) or a 19-in. cabinet by using the mounting brackets provided with the
switch. (The remainder of this topic uses “rack” to mean “rack or cabinet.”)
You can mount the switch on four posts of a four-post rack by using the mounting brackets
provided with the separately orderable four-post rack-mount kit. See “Mounting an
EX3200 Switch on Four Posts in a Rack or Cabinet” on page 146.
NOTE: If you need to mount the switch in a recessed position on either a
two-post rack or a four-post rack, you can use the 2-in.-recess front brackets
provided in the separately orderable four-post rack-mount kit.
Before mounting an EX3200 switch on two posts in a rack:
•
Verify that the site meets the requirements described in “Site Preparation Checklist
for EX3200 Switches” on page 57.
•
Place the rack in its permanent location, allowing adequate clearance for airflow and
maintenance, and secure it to the building structure.
•
Read “General Safety Guidelines and Warnings” on page 237, with particular attention
to “Chassis Lifting Guidelines” on page 246.
•
Remove the switch from the shipping carton (see “Unpacking an EX3200 Switch” on
page 137).
Ensure that you have the following parts and tools available:
•
Phillips (+) screwdriver, number 2
•
2 mounting brackets and 8 mounting screws (provided in the accessory box shipped
with the switch)
•
Screws to secure the chassis to the rack (not provided)
•
2-in.-recess front brackets if you will mount the switch in a recessed position (brackets
are from the separately orderable four-post rack-mount kit).
Copyright © 2016, Juniper Networks, Inc.144
EX3200 Switch Hardware Guide
