Juniper EX3200 Hardware Guide

• Connecting DC Power to an EX3200 Switch on page 163
• Connecting and Configuring an EX Series Switch (CLI Procedure) on page 175
• Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 178
• Mounting an EX3200 Switch in a Recessed Position in a Rack or Cabinet on page 150
• Rack-Mounting and Cabinet-Mounting Warnings on page 248
Mounting an EX3200 Switch in a Recessed Position in a Rack or Cabinet
You can mount an EX3200 switch in a rack or cabinet such that the switch is recessed
inside the rack from the rack front by 2 inches. You can use the 2-in.-recess front brackets
provided in the separately orderable four-post rack-mount kit to mount the switch in a
recessed position.
Reasons that you might want to mount the switch in a recessed position include:
•
You are mounting the switch in a cabinet and the cabinet doors will not close completely
unless the switch is recessed.
•
The switch you are mounting has an uplink module with transceivers installed in it—the
transceivers in the uplink module ports protrude from the front of the switch.
To mount the switch in a recessed position on four posts, follow the instructions in
“Mounting an EX3200 Switch on Four Posts in a Rack or Cabinet” on page 146. To mount
the switch in a recessed position on two posts, follow the instructions in “Mounting an
EX3200 Switch on Two Posts in a Rack or Cabinet” on page 144.
Related
Documentation
Connecting Earth Ground to an EX Series Switch on page 155•
• Rack-Mounting and Cabinet-Mounting Warnings on page 248
Mounting an EX3200 Switch on a Wall
You can mount an EX3200switch on a wall by using the separately orderablewall-mount
kit.
Before mounting an EX3200 switch on a wall:
•
Verify that the site meets the requirements described in “Site Preparation Checklist
for EX3200 Switches” on page 57.
•
Read “General Safety Guidelines and Warnings” on page 237, with particular attention
to “Chassis Lifting Guidelines” on page 246.
•
Remove the switch from the shipping carton (see “Unpacking an EX3200 Switch” on
page 137).
Ensure that you have the following parts and tools available:
Copyright © 2016, Juniper Networks, Inc.150
EX3200 Switch Hardware Guide

Juniper EX3200 Specifications

General

Model	EX3200
Rack Units	1U
Layer Support	Layer 2 and Layer 3
Junos OS	Yes
Maximum VLANs	4093
DRAM	512 MB
Flash Memory	256 MB
Ports	24 or 48
Uplink Ports	4 SFP
Power Supply	AC or DC
MAC Address Table Size	16, 000 entries
Dimensions (W x D x H)	17.4 x 14.4 x 1.7 inches
Weight	12.3 lb (5.6 kg)
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 85% (non-condensing)
