If there are 4 major alarms and 3 minor alarms, then details of the 4 major alarms and 1
minor alarm are displayed. Major alarms are displayed in red and minor alarms are
displayed in yellow.
In EX8200 Virtual Chassis, the top 5 alarms for the master external Routing Engine are
displayed by default. If you select an EX8200 member switch of the Virtual Chassis, the
top 5 alarms for that member switch are displayed.
File System Usage
To display the file system storage details of a switch in the backup or linecard role, click
the image of that switch.
Chassis Viewer
Click the Rear View button to see the back of the chassis image. Click the Front View
button to see the front of the chassis image. In a Virtual Chassis configuration, the Rear
View button is disabled if the switch is not selected.
•
Table 20 on page 42—Describes the chassis viewer for EX2200 switches.
•
Table 21 on page 43—Describes the chassis viewer for EX2200-C and EX2300-C
switches.
•
Table 22 on page 44—Describes the chassis viewer for EX2300 switches.
•
Table 23 on page 45—Describes the chassis viewer for EX3200, EX3300, and EX4200
switches.
•
Table 24 on page 46—Describes the chassis viewer for EX3400 and EX4300 switches.
•
Table 25 on page 48—Describes the chassis viewer for EX4500 switches.
•
Table 26 on page 49—Describes the chassis viewer for EX4550 switches.
•
Table 27 on page 50—Describes the chassis viewer for EX6210 switches.
•
Table 28 on page 50—Describes the chassis viewer for EX8208 switches.
•
Table 29 on page 52—Describes the chassis viewer for EX8216 switches.
•
Table 30 on page 52—Describes the chassis viewer for the XRE200 External Routing
Engines.
Table 20: Chassis Viewer for EX2200 Switches
DescriptionField
Front View
In the image, the following colors denote the interface status:
•
Green—Interface is up and operational.
•
Yellow—Interface is up but is nonoperational.
•
Gray—Interface is down and nonoperational.
Mouse over the interface (port) to view more information.
Interface status
Copyright © 2016, Juniper Networks, Inc.42
EX3200 Switch Hardware Guide

Juniper EX3200 Specifications

General

Model	EX3200
Rack Units	1U
Layer Support	Layer 2 and Layer 3
Junos OS	Yes
Maximum VLANs	4093
DRAM	512 MB
Flash Memory	256 MB
Ports	24 or 48
Uplink Ports	4 SFP
Power Supply	AC or DC
MAC Address Table Size	16, 000 entries
Dimensions (W x D x H)	17.4 x 14.4 x 1.7 inches
Weight	12.3 lb (5.6 kg)
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 85% (non-condensing)
