Page #148 background imageLoading...
Page #148 background image
Table 52: QSFP+ Network Port Connector Pinout Information (continued)
SignalPin
TX1p36
TX1n37
GND38
Related
Documentation
Installing a Transceiver on page 201
RJ-45 to DB-9 Serial Port Adapter Pinout Information
The console port is an RS-232 serial interface that uses an RJ-45 connector to connect
to a management device such as a PC or a laptop. If your laptop or PC does not have a
DB-9 male connector pin and you want to connect your laptop or PC to the device, use
a combination of the RJ-45 to DB-9 female adapter along with a USB to DB-9 male
adapter.
Table 53 on page 126 provides the pinout information for the RJ-45 to DB-9 serial port
adapter.
Table 53: RJ-45 to DB-9 Serial Port Adapter Pinout Information
SignalDB-9 PinSignalRJ-45 Pin
CTS8RTS1
DSR6DTR2
RXD2TXD3
GND5GND4
TXD3RXD6
DTR4DSR7
RTS7CTS8
Related
Documentation
Connecting a Deviceto a Management Console by Using an RJ-45Connector on page168
Uplink Modules Connector Pinout Information for EX3200 Switches
EX3200 switches have a field-replaceable unit (FRU) uplink module on the front panel.
Table 54 on page 127 provides the uplink modules connector pinout information.
Copyright © 2016, Juniper Networks, Inc.126
EX3200 Switch Hardware Guide
