Table 52: QSFP+ Network Port Connector Pinout Information (continued)

SignalPin

SDA12

GND13

RX3p14

RX3n15

GND16

RX1p17

RX1n18

GND19

GND20

RX2n21

RX2p22

GND23

RX4n24

RX4p25

GND26

ModPrsL27

IntL28

VccTx29

Vcc130

Reserved31

GND32

TX3p33

TX3n34

GND35

125Copyright © 2016, Juniper Networks, Inc.
