Juniper EX3200 Hardware Guide

4. Follow instructions for connecting power as appropriate for your site:
•
Connecting AC Power to an EX3200 Switch on page 161
•
Connecting DC Power to an EX3200 Switch on page 163
5. Perform initial configuration of the switch by following instructions in “Connecting
and Configuring an EX Series Switch (CLI Procedure)” on page 175 or “Connecting and
Configuring an EX Series Switch (J-Web Procedure)” on page 178.
6. Set the switch’s management options by following the appropriate instructions:
•
Connecting a Device to a Network for Out-of-Band Management on page 167
•
Connecting a Device to a Management Console by Using an RJ-45 Connector on
page 168
Related
Documentation
Rack Requirements on page 64•
• Cabinet Requirements on page 65
• Clearance Requirements for Airflow and Hardware Maintenance for EX3200 Switches
on page 66
Mounting an EX3200 Switch
You can mount the switch:
•
On two posts in a 19-in. rack or cabinet by using the mounting brackets provided with
the switch.
•
On four posts in a 19-in. rack or cabinet by using the separately orderable four-post
rack-mount kit.
•
In a position recessed 2 in. from the front of a 19-in. rack or cabinet by using the
2-in.-recess front brackets in the separately orderable four-post rack-mount kit. You
can mount the switch in this recessed position on two-post or four-post racks and
cabinets.
•
On a desk or other level surface by using rubber feet. The switch is shipped with four
rubber feet to be used to stabilize the chassis on a desk or other level surface.
•
On a wall by using the separately orderable wall-mount kit.
The holes in the mounting brackets are placed at 1 U (1.75 in. or 4.45 cm.) apart so that
the switch can be mounted in any rack or cabinet that provides holes spaced at that
distance.
See the Related Documentation for detailed descriptions of the various rack or cabinet
mounting options.
Related
Documentation
Mounting an EX3200 Switch on Two Posts in a Rack or Cabinet on page 144•
• Mounting an EX3200 Switch on Four Posts in a Rack or Cabinet on page 146
• Mounting an EX3200 Switch in a Recessed Position in a Rack or Cabinet on page 150
Copyright © 2016, Juniper Networks, Inc.142
EX3200 Switch Hardware Guide

Juniper EX3200 Specifications

General

Model	EX3200
Rack Units	1U
Layer Support	Layer 2 and Layer 3
Junos OS	Yes
Maximum VLANs	4093
DRAM	512 MB
Flash Memory	256 MB
Ports	24 or 48
Uplink Ports	4 SFP
Power Supply	AC or DC
MAC Address Table Size	16, 000 entries
Dimensions (W x D x H)	17.4 x 14.4 x 1.7 inches
Weight	12.3 lb (5.6 kg)
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 85% (non-condensing)
