options. After the boot process is complete, the LCD panel automatically reverts to the
Idle menu.
In an EX3200 switch, the first line of the LCD panel displays the hostname.
In the idle mode, the second line displays the mode of the network ports’ Status LED and
the number of chassis alarms. The number of alarms is updated every second.
In the status mode, the second line displays:
•
Status of the power supply
•
Status of the fan and temperature
•
Version of Junos OS for EX Series switches loaded on the switch
In the maintenance mode, the second line displays one of the following options that you
can use to configure or troubleshoot the switch:
•
System halt
•
System reboot
•
Load rescue
•
Factory default
•
System EZSetup
LCD Panel Menus
The LCD panel has three menus: Idle, Status, and Maintenance. Toggle between the LCD
panel menus by pressing the Menu button. Navigate through the menu options by pressing
the Enter button.
Table 6 on page 12 describes the LCD panel menu options.
Table 6: LCD Panel Menu Options
DescriptionMenu
In the Idle menu:
•
Press Enter to cycle through the Status LED modes:
•
SPD (speed)
•
ADM (administrative status)
•
DPX (duplex)
•
POE (Power over Ethernet)
See “Network Port LEDs in EX3200 Switches” on page 21 or Network Port LEDs in EX4200 Switches for
information about the Status LED modes.
•
Press Menu to exit the Idle menu and go to the Status menu.
IDLE
Copyright © 2016, Juniper Networks, Inc.12
EX3200 Switch Hardware Guide

Juniper EX3200 Specifications

General

Model	EX3200
Rack Units	1U
Layer Support	Layer 2 and Layer 3
Junos OS	Yes
Maximum VLANs	4093
DRAM	512 MB
Flash Memory	256 MB
Ports	24 or 48
Uplink Ports	4 SFP
Power Supply	AC or DC
MAC Address Table Size	16, 000 entries
Dimensions (W x D x H)	17.4 x 14.4 x 1.7 inches
Weight	12.3 lb (5.6 kg)
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 85% (non-condensing)
