Table 43: Optical Interface Support for Gigabit Ethernet XFP Transceivers in EX3200 Switches

ValueSpecificationEthernet Standard

EX-XFP-10GE-SRModel number10GBASE-SR

10 GbpsRate

LCConnector type

DualFiber count

850 nmTransmitter wavelength

–7.3 dBmMinimum launch power

–1.3 dBmMaximum launch power

–11.1 dBmMinimum receiver sensitivity

–1 dBmMaximum input power

MMFFiber type

50/125

µm

50/125

µm

50/125

µm

62.5/125

µm

62.5/125

µm

Core/Cladding size

OM3OM2–OM1FDDIFiber grade

1500

MHz/km

500

MHz/km

400

MHz/km

200

MHz/km

160

MHz/km

Modal bandwidth

300 m

(984 ft)

82 m

(269 ft)

66 m

(216 ft)

33 m

(108 ft)

26 m

(85 ft)

Distance

AvailableDOM support

Junos OS for EX Series switches, Release 9.0 or laterSoftware required
