Juniper EX3200 Hardware Guide

CHAPTER 2
Chassis Components and Descriptions
•
Chassis Physical Specifications for EX3200 Switches on page 7
•
Field-Replaceable Units in EX3200 Switches on page 8
•
Front Panel of an EX3200 Switch on page 9
•
Rear Panel of an EX3200 Switch on page 10
•
LCD Panel in EX3200 Switches on page 11
•
Uplink Modules in EX3200 Switches on page 15
•
Chassis Status LEDs in EX3200 Switches on page 18
•
Management Port LEDs in EX3200 Switches on page 20
•
Network Port LEDs in EX3200 Switches on page 21
Chassis Physical Specifications for EX3200 Switches
The EX3200 switch chassis is a rigid sheet-metal structure that houses the hardware
components. Table 5 on page 7 summarizes the physical specifications of the EX3200
switch chassis.
Table 5: Physical Specifications of the Switch Chassis
ValueDescription
1.75 in. (4.45 cm)Chassis height
•
17.25 in. (43.82 cm)
•
19 in. (48.2 cm) with mounting brackets attached
Chassis width
•
Without power supply installed—17 in. (43.18 cm)
•
With power supply installed:
•
320 W AC power supply or 190 W DC power supply installed—17 in. (43.18 cm)
•
600 W or 930 W AC power supply installed—19.25 in. (48.9 cm)
Chassis depth
•
320 W AC power supply: 2.5 lb (1.1 kg)
•
600 W and 930 W AC power supplies: 3.1 lb (1.4 kg)
•
190 W DC power supply: 2.5 lb (1.1 kg)
Weight
7Copyright © 2016, Juniper Networks, Inc.

Juniper EX3200 Specifications

General

Model	EX3200
Rack Units	1U
Layer Support	Layer 2 and Layer 3
Junos OS	Yes
Maximum VLANs	4093
DRAM	512 MB
Flash Memory	256 MB
Ports	24 or 48
Uplink Ports	4 SFP
Power Supply	AC or DC
MAC Address Table Size	16, 000 entries
Dimensions (W x D x H)	17.4 x 14.4 x 1.7 inches
Weight	12.3 lb (5.6 kg)
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 85% (non-condensing)
