Table 24: Chassis Viewer for EX3400 and EX4300 Switches (continued)
DescriptionField
You can install an uplink module in the PIC 2 slot. Mouse over the ports in the module to view the
details of the ports in module.
24-port and 48-port EX4300 switches support the 4-port 10-Gigabit Ethernet SFP+ uplink module.
24-port and 48-port EX3400 switches support the 4-port 10-Gigabit Ethernet uplink ports.
EX4300-32F switches support the 2-port 40-Gigabit Ethernet uplink module and the 8-port
10-Gigabit Ethernet SFP+ uplink module.
When you install a transceiver in the port, the following colors denote the interface status:
•
Green—Interface is up and operational.
•
Yellow—Interface is up but is not operational.
•
Gray—Interface is down and not operational.
PIC 2 slot
NOTE: In EX3400 and EX4300 switches, the LEDs are seen in the front panel, these are not active.
Rear View of the EX3400 and EX4300 Switch
The management port is used to connect the switch to a management device for out-of-band
management.
Management port
The console port (RJ-45) is used to connect the switch to a management console or to a console
server.
Console port
Indicates the USB port for the switch.
NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your
EX Series switch.
USB port
Mouse over the fan tray icons to display name, status, and description information.Fan tray
Mouse over the power supply icons to display name, status, and description information.Power supplies
The rear panel of a 24-port and a 48-port EX4300 switch has four (built-in) 40-Gigabit Ethernet
ports. The rear panel of a 24-port and a 48-port EX3400 switch and an EX4300-32F switch has
two (built-in) 40-Gigabit Ethernet ports, in which you can install QSFP+ transceivers. Mouse over
the ports to view the details of the ports.
After you install a transceiver in the port, the following colors denote the interface status:
•
Green—Interface is up and operational.
•
Yellow—Interface is up but is not operational.
•
Gray—Interface is down and not operational.
For 40-Gigabit Ethernet ports, the interfaces appeardimmed if no transceiver is inserted. The chassis
viewer displays Transceiver not plugged in when you mouse over the port.
When a 40-Gigabit Ethernet port is configured as a VCP, the following colors denote the VCP status:
•
Green—VCP is up and operational.
•
Yellow—VCP is up but is not operational.
•
Gray—VCP is down and not operational.
PIC 1 slot
47Copyright © 2016, Juniper Networks, Inc.
Chapter 5: Viewing System Information

Juniper EX3200 Specifications

General

Model	EX3200
Rack Units	1U
Layer Support	Layer 2 and Layer 3
Junos OS	Yes
Maximum VLANs	4093
DRAM	512 MB
Flash Memory	256 MB
Ports	24 or 48
Uplink Ports	4 SFP
Power Supply	AC or DC
MAC Address Table Size	16, 000 entries
Dimensions (W x D x H)	17.4 x 14.4 x 1.7 inches
Weight	12.3 lb (5.6 kg)
Operating Temperature	0°C to 40°C
Operating Humidity	10% to 85% (non-condensing)
