Table 42: Optical interface Support for Gigabit Ethernet XFP Transceivers in EX4200 Switches
ValueSpecificationEthernet Standard
EX-XFP-10GE-SRModel number10GBASE-SR
10 GbpsRate
LCConnector type
DualFiber count
850 nmTransmitter wavelength
–7.3 dBmMinimum launch power
–1.3 dBmMaximum launch power
–11.1 dBmMinimum receiver sensitivity
–1 dBmMaximum input power
MMFFiber type
50/125 µm50/125 µm50/125 µm62.5/125µm62.5/125µmCore/Cladding size
OM3OM2–OM1FDDIFiber grade
1500
MHz/km
500
MHz/km
400
MHz/km
200
MHz/km
160
MHz/km
Modal bandwidth
300 m
(984 ft)
82 m
(269 ft)
66 m
(216 ft)
33 m
(108 ft)
26 m
(85 ft)
Distance
AvailableDOM support
EX4200-24T, EX4200-24T-DC, EX4200-24P, EX4200-24PX,
EX4200-24F, EX4200-24F-DC, EX4200-48T, EX4200-48T-DC,
EX4200-48P, and EX4200-48PX switches—Junos OS for
EX Series switches, Release 9.0 or later
EX4200-24F-S and EX4200-48T-S switches—Junos OS for
EX Series switches, Release 12.3R4 or later
Software required
YesSupport for Virtual Chassis
configuration on EX4200
switches
113Copyright © 2015, Juniper Networks, Inc.
Chapter 8: Transceiver and Cable Specifications

Juniper EX4200 Specifications

General

Model	EX4200
Switching Capacity	128 Gbps
Layer	Layer 2 and Layer 3
Form Factor	1U
Throughput	96 Mpps
Maximum VLANs	4096
MAC Address Table Size	16, 000
DRAM	1 GB
Flash Memory	1 GB
Forwarding Rate	96 Mpps
JUNOS Software	Yes
Ports	24 or 48
Stacking	Up to 10 switches in a Virtual Chassis configuration
Power Supply	AC or DC
Management	CLI, SNMP, J-Web
Input Voltage	100-240 VAC or -48 VDC
Operating Temperature	0°C to 45°C
Redundancy	Redundant power supplies
Virtual Chassis Technology	Yes
Storage Temperature	-40°C to 70°C
Humidity	5% to 90% non-condensing
