Juniper EX4200 User Manual

In the maintenance mode, the second line displays one of the following options that you
can use to configure and troubleshoot the switch:
•
System halt
•
System reboot
•
Load rescue
•
Request VC port (for an EX4200 switch that is a member of a Virtual Chassis)
•
Factory default
•
System EZSetup
LCD Panel Menus
The LCD panel has three menus: Idle, Status, and Maintenance. Toggle between the LCD
panel menus by pressing the Menu button. Navigate through the menu options by pressing
the Enter button.
Table 6 on page 15 describes the LCD panel menu options.
Table 6: LCD Panel Menu Options
DescriptionMenu
In the Idle menu:
•
Press Enter to cycle through the Status LED modes:
•
SPD (speed)
•
ADM (administrative status)
•
DPX (duplex)
•
POE (Power over Ethernet)
See Network Port LEDs in EX3200 Switches or “Network Port LEDs in EX4200 Switches” on page 24 for
information on the Status LED modes.
•
Press Menu to exit the Idle menu and go to the Status menu.
IDLE
15Copyright © 2015, Juniper Networks, Inc.
Chapter 2: Chassis Components and Descriptions

Juniper EX4200 Specifications

General

Model	EX4200
Switching Capacity	128 Gbps
Layer	Layer 2 and Layer 3
Form Factor	1U
Throughput	96 Mpps
Maximum VLANs	4096
MAC Address Table Size	16, 000
DRAM	1 GB
Flash Memory	1 GB
Forwarding Rate	96 Mpps
JUNOS Software	Yes
Ports	24 or 48
Stacking	Up to 10 switches in a Virtual Chassis configuration
Power Supply	AC or DC
Management	CLI, SNMP, J-Web
Input Voltage	100-240 VAC or -48 VDC
Operating Temperature	0°C to 45°C
Redundancy	Redundant power supplies
Virtual Chassis Technology	Yes
Storage Temperature	-40°C to 70°C
Humidity	5% to 90% non-condensing
