Connecting and Configuring an EX Series Switch (J-Web Procedure)
There are two ways to connect and configure an EX Series switch: one method is through
the console by using the CLI and the other is by using the J-Web interface.
NOTE: EX2200-24T-4G-DC switches do not support switch connection and
configuration through J-Web procedure.
This topic describes the J-Web procedure.
NOTE: Before you begin the configuration, enable a DHCP client on the
management PCthat you will connect to the switch so that thePC can obtain
an IP address dynamically.
NOTE: Read the following steps before you begin the configuration. You
must complete the initial configuration by using EZSetup within 10 minutes.
The switch exits EZSetup after 10 minutes and reverts to the factory default
configuration, and the PC loses connectivity to the switch.
•
EX2200 and EX2200-C switch—The LEDs on the network ports on the
front panel blink when the switch is in the initial setup mode.
•
EX3200,EX3300, EX4200,EX4300,EX4500,EX4550,EX6200, or EX8200
switch—The LCD panel displays a count-down timer when the switch is in
initial setup mode.
Copyright © 2015, Juniper Networks, Inc.198
EX4200 Switch Hardware Guide

Juniper EX4200 Specifications

General

Model	EX4200
Switching Capacity	128 Gbps
Layer	Layer 2 and Layer 3
Form Factor	1U
Throughput	96 Mpps
Maximum VLANs	4096
MAC Address Table Size	16, 000
DRAM	1 GB
Flash Memory	1 GB
Forwarding Rate	96 Mpps
JUNOS Software	Yes
Ports	24 or 48
Stacking	Up to 10 switches in a Virtual Chassis configuration
Power Supply	AC or DC
Management	CLI, SNMP, J-Web
Input Voltage	100-240 VAC or -48 VDC
Operating Temperature	0°C to 45°C
Redundancy	Redundant power supplies
Virtual Chassis Technology	Yes
Storage Temperature	-40°C to 70°C
Humidity	5% to 90% non-condensing
