Table 44: SFP+ Direct Attach Cable Specifications (continued)
ValueSpecificationModel Number
10-Gbps full-duplex serial transmissionRateEX-SFP-10GE-DAC-7M
SFP+ passive Twinax cable assemblyConnector type
3.3 VSupply voltage
0.57 WPower consumption (per end)
–40
°
C through 85
°
CStorage temperature
TwinaxCable type
24 AWGWire AWG
1 in. (2.54 cm)Minimum cable bend radius
100 ohmsCable characteristic impedance
2% maximumCrosstalk between pairs
1.31 nsec/ftTime delay
23 ft (7 m)Length
Standards Supported by These Cables
The cables comply with the following standards:
SFP mechanical standard SFF-843—see ftp://ftp.seagate.com/sff/SFF-8431.PDF .
Electrical interface standard SFF-8432—see ftp://ftp.seagate.com/sff/SFF-8432.PDF .
SFP+ Multi-Source Alliance (MSA) standards.
Related
Documentation
Pluggable Transceivers Supported on EX Series Switches
Installing a Transceiver in an EX Series Switch on page 221
Removing a Transceiver from a Switch on page 223
Network Cable Specifications for EX4200 Switches
EX4200 switches have interfaces that use various types of network cables.
For instructions on connecting an EX4200 switch to a network for out-of-band
management using an Ethernet cable with an RJ-45 connector, see “Connecting a Switch
to a Network for Out-of-Band Management” on page 185.
