Page #180 background image
“Mounting an EX4200 Switch on a Desk or Other Level Surface” on page 159 (using
the rubber feet provided)
“Mounting an EX4200 Switch on a Wall” on page 167 (using the separately orderable
wall-mount kit)
5. Follow instructions in “Connecting Earth Ground to an EX Series Switch” on page 171.
6. Follow instructions for connecting power as appropriate for your site:
Connecting AC Power to an EX4200 Switch on page 177
Connecting DC Power to an EX4200 Switch on page 179
7. Perform initial configuration of the switch by following instructions in “Connecting
and Configuring an EX Series Switch (CLI Procedure)” on page 195 or “Connecting and
Configuring an EX Series Switch (J-Web Procedure)” on page 198.
8. Set the switch’s management options by following the appropriate instructions:
Connecting a Switch to a Network for Out-of-Band Management on page 185
Connecting a Switch to a Management Console on page 187
Related
Documentation
Rack Requirements for EX4200 Switches on page 69
Cabinet Requirements for EX4200 Switches on page 70
Clearance Requirements for Airflow and Hardware Maintenance for EX4200 Switches
on page 72
Mounting an EX4200 Switch
You can mount the switch:
On two posts in a 19-in. rack or cabinet by using the mounting brackets provided with
the switch.
On four posts in a 19-in. rack or cabinet by using the separately orderable four-post
rack-mount kit.
In a position recessed 2 in. from the front of a 19-in. rack or cabinet by using the
2-in.-recess front brackets in the separately orderable four-post rack-mount kit. You
can mount the switch in this recessed position on two-post or four-post racks and
cabinets.
On a desk or other level surface by using rubber feet. The switch is shipped with four
rubber feet to be used to stabilize the chassis on a desk or other level surface.
On a wall by using the separately orderable wall-mount kit.
The holes in the mounting brackets are placed at 1 U (1.75 in. or 4.45 cm.) apart so that
the switch can be mounted in any rack or cabinet that provides holes spaced at that
distance.
