CHAPTER 29
Radiation and Laser Safety Guidelines and
Warnings
•
Laser and LED Safety Guidelines and Warnings for Switches on page 287
•
Radiation from Open Port Apertures Warning on page 290
Laser and LED Safety Guidelines and Warnings for Switches
EX Series switches, OCX1100 switches, and the XRE200 External Routing Engine are
equipped with laser transmitters, which are considered a Class 1 Laser Product by the
U.S. Food and Drug Administration and are evaluated as a Class 1 Laser Product per EN
60825-1 requirements.
Observe the following guidelines and warnings:
•
General Laser Safety Guidelines on page 287
•
Class 1 Laser Product Warning on page 288
•
Class 1 LED Product Warning on page 288
•
Laser Beam Warning on page 289
General Laser Safety Guidelines
When working around ports that support optical transceivers, observe the following
safety guidelines to prevent eye injury:
•
Do not look into unterminated ports or at fibers that connect to unknown sources.
•
Do not examine unterminated optical ports with optical instruments.
•
Avoid direct exposure to the beam.
WARNING: Unterminated optical connectors can emit invisible laser
radiation. The lens in the human eye focuses all the laser power on the
retina, so focusing the eye directly on a laser source—even a low-power
laser—could permanently damage the eye.
287Copyright © 2015, Juniper Networks, Inc.

Juniper EX4200 Specifications

General

Model	EX4200
Switching Capacity	128 Gbps
Layer	Layer 2 and Layer 3
Form Factor	1U
Throughput	96 Mpps
Maximum VLANs	4096
MAC Address Table Size	16, 000
DRAM	1 GB
Flash Memory	1 GB
Forwarding Rate	96 Mpps
JUNOS Software	Yes
Ports	24 or 48
Stacking	Up to 10 switches in a Virtual Chassis configuration
Power Supply	AC or DC
Management	CLI, SNMP, J-Web
Input Voltage	100-240 VAC or -48 VDC
Operating Temperature	0°C to 45°C
Redundancy	Redundant power supplies
Virtual Chassis Technology	Yes
Storage Temperature	-40°C to 70°C
Humidity	5% to 90% non-condensing
