CHAPTER 18
Replacing Uplink Module
•
Installing an Uplink Module in an EX4200 Switch on page 215
•
Removing an Uplink Module from an EX4200 Switch on page 217
Installing an Uplink Module in an EX4200 Switch
If your EX4200 switch includes an optional uplink module, you install it in the switch's
front panel. The different types of uplink modules are described in “Uplink Modules
Connector Pinout Information for EX4200 Switches” on page 130.
Theuplink module in EX4200 switchesis a hot-removable and hot-insertableunit (FRU):
You can remove and replace it without powering off the switch.
NOTE: The packet forwarding process (pfem) restarts and causes traffic
loss, if you:
•
Install an uplink module (SFP, SFP+, SFP+ MACsec, or XFP)
•
Replace an existing uplink module with another uplink module
•
Change the operating mode of an SFP+ or SFP+ MACsec uplink module
(10-gigabit to 1-gigabit or 1-gigabit to 10-gigabit) installed in the switch
NOTE: If you have set an uplink module port as a Virtual Chassis port (VCP),
removing the uplink module breaks the setting. You must reset the port as a
VCP after you replace the module. See Setting an Uplink Port on an EX Series
Switch as a Virtual Chassis Port (CLI Procedure).
Before you begin installing an uplink module in the switch:
•
Ensure that you have taken the necessary precautions to prevent ESD damage (see
“Prevention of Electrostatic Discharge Damage” on page 301).
Ensure that you have the following parts and tools available:
•
Electrostatic discharge (ESD) grounding strap (If a grounding strap is not available,
follow the alternative grounding method described in Step 1 of the following procedure.)
215Copyright © 2015, Juniper Networks, Inc.
