SFP+ uplink module ports configured as VCPs
•
On EX4550 switches:
•
The dedicated VCPs on the Virtual Chassis module
•
SFP+ network ports configured as VCPs
•
SFP+ expansion module ports configured as VCPs
•
10GBASE-T network ports configured as VCPs
•
10GBASE-T expansion module ports configured as VCPs
•
40G QSFP+ expansion module ports configured as VCPs
NOTE: You can use the 10GBASE-T Ethernet network ports, 10GBASE-T
expansion module ports, and QSFP+ expansion module ports configured
as VCPs to interconnect only EX4550 switches in a Virtual Chassis. These
ports cannot be used to connectan EX4550 switch with an EX4200 switch
or an EX4500 switch in a Virtual Chassis.
Number of Switches, Required Software Releases, and Member Roles That You Configure in
the Virtual Chassis
A Virtual Chassis must have one member designated as the master switch and one
member designated as the backup switch. All other switches in the configuration are
designated as being in the linecard role. You manage Virtual Chassis operation through
the master switch.
The number of switches that you can configure in a Virtual Chassis and the role that can
be assigned to each switch in a Virtual Chassis depend on the Juniper Networks Junos
operating system (Junos OS) release that is running on the switches.
See the following tables:
•
Table 51 on page 144—EX4200 Virtual Chassis
•
Table 52 on page 145—EX4500 Virtual Chassis
•
Table 53 on page 145—EX4550 Virtual Chassis
•
Table 54 on page 145—Mixed EX4200, EX4500, and EX4550 Virtual Chassis
Table 51: Number of Switches and Switch Roles for an EX4200 Virtual Chassis, per Junos OS
Release
RoleNumber of SwitchesJunos OS Release
There must be a master and a backup; the remaining switches must
be in the linecard role.
Up to 10 EX4200 switches9.0 or later
Copyright © 2015, Juniper Networks, Inc.144
EX4200 Switch Hardware Guide

Juniper EX4200 Specifications

General

Model	EX4200
Switching Capacity	128 Gbps
Layer	Layer 2 and Layer 3
Form Factor	1U
Throughput	96 Mpps
Maximum VLANs	4096
MAC Address Table Size	16, 000
DRAM	1 GB
Flash Memory	1 GB
Forwarding Rate	96 Mpps
JUNOS Software	Yes
Ports	24 or 48
Stacking	Up to 10 switches in a Virtual Chassis configuration
Power Supply	AC or DC
Management	CLI, SNMP, J-Web
Input Voltage	100-240 VAC or -48 VDC
Operating Temperature	0°C to 45°C
Redundancy	Redundant power supplies
Virtual Chassis Technology	Yes
Storage Temperature	-40°C to 70°C
Humidity	5% to 90% non-condensing
