Virtual Chassis Ports Connector Pinout Information for EX4200 Switches
EX4200 switchesuse a 68-pin connectorcable to interconnect switches to form a Virtual
Chassis. The cable is provided with the switch. Table 50 on page 138 provides the Virtual
Chassis ports (VCPs) connector pinout information.
Table 50: Virtual Chassis Ports (VCPs) Connector Pinout Information
Pin NamePin Number
GNDA1
P1TXP0A2
P1TXN0A3
GNDA4
P1TXP1A5
P1TXN1A6
GNDA7
P1TXP2A8
P1TXN2A9
GNDA10
P1TXP3A11
P1TXN3A12
GNDA13
NCA14
NCA15
GNDA16
NCA17
NCA18
NCA19
NCA20
Copyright © 2015, Juniper Networks, Inc.138
EX4200 Switch Hardware Guide
