Juniper EX4200 User Manual

• Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 198
Uplink Modules in EX4200 Switches
EX4200 switches support four types of uplink modules:
•
SFP uplink module—Provides four ports for 1-gigabit small form-factor pluggable(SFP)
transceivers.
•
SFP+ uplink module—Provides two ports for 10-gigabit small form-factor pluggable
(SFP+) transceivers when configured to operate in 10-gigabit mode or four ports for
1-gigabit small form-factor pluggable (SFP) transceivers when configured to operate
in 1-gigabit mode.
•
SFP+ Media Access Control Security (MACsec) uplink module—Provides two ports for
10-gigabit small form-factor pluggable (SFP+) transceivers when configured to operate
in 10-gigabit mode or four ports for 1-gigabit small form-factor pluggable (SFP)
transceivers when configured to operate in 1-gigabit mode. All four ports on the uplink
module are MACsec-capable.
•
XFP uplink module—Provides two ports for 10-gigabit small form-factor pluggable
(XFP) transceivers.
NOTE: When a new uplink module is installed in the switch or an existing
uplink module is replaced with another uplink module, the switch detects
the newly installed uplink module. The switch creates the required interfaces
if the uplink module has transceivers in its ports and when new transceivers
are installed in those ports.
NOTE: The packet forwarding process (pfem) restarts and causes traffic
loss, if you:
•
Install an uplink module (SFP, SFP+, SFP+ MACsec, or XFP)
•
Replace an existing uplink module with another uplink module
•
Change the operating mode of an SFP+ or SFP+ MACsec uplink module
(10-gigabit to 1-gigabit or 1-gigabit to 10-gigabit) installed in the switch
When connecting uplink module ports, you can install an SFP uplink module at one end
of the connection and install an SFP+ uplink module configured to operate in the 1-gigabit
mode at the other end. Likewise, you can install an XFP uplink module at one end of the
connection and install an SFP+ uplink module configured to operate in the 10-gigabit
mode at the other end.
Copyright © 2015, Juniper Networks, Inc.18
EX4200 Switch Hardware Guide

Juniper EX4200 Specifications

General

Model	EX4200
Switching Capacity	128 Gbps
Layer	Layer 2 and Layer 3
Form Factor	1U
Throughput	96 Mpps
Maximum VLANs	4096
MAC Address Table Size	16, 000
DRAM	1 GB
Flash Memory	1 GB
Forwarding Rate	96 Mpps
JUNOS Software	Yes
Ports	24 or 48
Stacking	Up to 10 switches in a Virtual Chassis configuration
Power Supply	AC or DC
Management	CLI, SNMP, J-Web
Input Voltage	100-240 VAC or -48 VDC
Operating Temperature	0°C to 45°C
Redundancy	Redundant power supplies
Virtual Chassis Technology	Yes
Storage Temperature	-40°C to 70°C
Humidity	5% to 90% non-condensing
