Table 11: Status LED on Network Ports
State and DescriptionLCD IndicatorLED
Indicates the administrative status (enabled or disabled). The
status indicators are:
Green—Administrative status enabled.
Unlit—Administrative status disabled.
LED: ADMStatus
Indicates the duplex mode.
The uplink module ports are always set to full-duplex; therefore,
the LED is always green.
The status indicators for network ports on the front panel are:
Green—Port is set to full-duplex mode.
Unlit—Port is set to half-duplex mode.
LED: DPX
Indicates the MACsec status (enabled or disabled). MACsec can
be enabled only if you have installed the SFP+ MACsec uplink
module. The status indicators are:
Green—MACsec is enabled on the port.
Unlit—MACsec is disabled on the port.
LED: MACsec
Indicates the PoE status on switches with PoE-enabled ports.
Here the term POE refers to both PoE and PoE+ as applicable.
PoE is not enabled on uplink module ports; therefore, the LED for
those ports is always unlit.
The status indicators for network ports on the front panel are:
Green—PoE is enabled on the port.
Amber—PoE is enabled on the port, but no power is drawn from
the port because of one of the following:
No device that draws power from the port is connected to the
port.
A device that draws power from the port is connected to the
port, but the device is not drawing any power from the port.
Unlit—PoE is not enabled on the port.
LED: POE
Indicates the speed.LED: SPD
The speed indicators for network ports on the front panel are:
One blink per second—10 Mbps
Two blinks per second—100 Mbps
Three blinks per second—1000 Mbps
The speed indicators for network ports on the SFP uplink module
are:
Green—1000 Mbps
Unlit—10/100 Mbps
Copyright © 2015, Juniper Networks, Inc.28
EX4200 Switch Hardware Guide
