Table 11: Status LED on Network Ports (continued)
State and DescriptionLCD IndicatorLED
The speed indicators for network ports on the SFP+ and SFP+
MACsec uplink module are:
Green—The speed of the transceiver installed in the port is the
same as the speed at which the uplink module port is configured
to operate.
Unlit—The speed of the transceiver installed in the port is not
the same as the speed at which the uplink module port is
configured to operate.
The speed of the XFP uplink module ports is always 10 Gbps, which
is also the speed of XFP transceivers, therefore, this LED is always
green on an XFP uplink module..
Related
Documentation
Front Panel of an EX4200 Switch on page 11
Uplink Modules in EX4200 Switches on page 18
LCD Panel in EX4200 Switches on page 13
