Table 49: Uplink Modules Connector Pinout Information (continued)
Pin NamePin Number
POWER (12V)A19
GNDA20
GNDB1
XAUI0_RX0NB2
GNDB3
XAUI0_RX2NB4
Uplink_P25_LED2B5
XAUI1_RX0NB6
Uplink_P27_LED2B7
XAUI1_RX2NB8
GNDB9
SRX28NB10
Uplink_XAUI_XMDIOB11
SRX26NB12
GNDB13
SGMIIRXNB14
Uplink_I2C_RstB15
Uplink_IntrB16
Uplink_Pwr_EnB17
Uplink_P26_LED0B18
POWER (12V)B19
POWER (12V)B20
GNDC1
XAUI0_RX0PC2
131Copyright © 2015, Juniper Networks, Inc.
Chapter 9: Pinout Specifications
