Table 49: Uplink Modules Connector Pinout Information (continued)
Pin NamePin Number
XAUI1_TX1ND7
GNDD8
XAUI1_TX3ND9
GNDD10
STX27ND11
GNDD12
STX25ND13
GNDD14
Uplink_RstD15
GNDD16
Uplink_Status_LED0D17
GNDD18
POWER (12V)D19
GNDD20
GNDE1
XAUI0_TX0NE2
XAUI0_TX1PE3
XAUI0_TX2NE4
XAUI0_TX3PE5
XAUI1_TX0NE6
XAUI1_TX1PE7
XAUI1_TX2NE8
XAUI1_TX3PE9
STX28NE10
