Table 50: Virtual Chassis Ports (VCPs) Connector Pinout Information (continued)

Pin NamePin Number

P1RXP3B11

P1RXN3B12

GNDB13

NCB14

NCB15

NCB16

NCB17

NCB18

NCB19

NCB20

NCB21

GNDB22

P2RXP0B23

P2RXN0B24

GNDB25

P2RXP1B26

P2RXN1B27

GNDB28

P2RXP2B29

P2RXN2B30

GNDB31

P2RXP3B32

P2RXN3B33

GNDB34

Copyright © 2015, Juniper Networks, Inc.140
