Unpacking an EX4600 Switch
The EX4600 switch chassis is a rigid sheet-metal structure that houses the hardware
components. A EX4600 switch is shipped in a cardboard carton, secured with foam
packing material. The carton also contains an accessory box and quick start instructions.
CAUTION: EX4600 switches are maximally protected inside the shipping
carton. Do not unpack the switch until you are ready to begin installation.
To unpack a EX4600 switch:
1. Move the shipping carton to a staging area as close to the installation site as possible,
but where you have enough room to remove the system components.
2. Position the carton so that the arrows are pointing up.
3. Open the top flaps on the shipping carton.
4. Remove the accessory box and verify the contents against the inventory included in
the box.Table35 on page140 lists the inventory of components supplied with a EX4600
switch.
5. Pull out the packing material holding the switch in place.
6. Verify the chassis components received:
•
Two power supplies
•
Five fan modules
7. Save the shipping carton and packing materials in case you need to move or ship the
switch later.
Table 35: Inventory of Components Supplied with an EX4600 Switch
QuantityComponent
1Chassis with five fan modules and two power supplies.
2Rear mounting blades
2Front mounting brackets
2Extension brackets
1RJ-45 cable and RJ-45 to DB-9 adapter
Related
Documentation
Mounting an EX4600 Switch in a Rack or Cabinet on page 141•
• Installing and Connecting an EX4600 Switch on page 139
